STANDARD FEATURES INCLUDE:
• Automatic Frequency Tuning
• Weld, Hold, Delay and After-burst Timers
• Back-Lit HMI Display
• Ultrasonics Load Meter Scale
• Upper and Lower Weld Limit Settings
• Soft-start Overload Protection Circuitry
• Load Regulation Circuitry
• Digital Wattage Display
• Built in the USA by Sharpertek with German Sonics
Specifications, additional features, and options:
| Microprocessor with Swivel HMI | Standard |
|
Dual Cycle Start Buttons |
Standard |
| Non-Contact Cycle Start Buttons |
Optional |
| Front Emergency Stop | Standard |
| Head Adjust | Standard |
| Counterbalance Spring | Standard |
| Adjustable Positive Stop | Standard |
| Automation Limit Switches |
Optional |
| Rigid Mount Booster |
Optional |
| Extended Length Column |
Optional |
| Stroke Air Cylinder |
8" |
| Air Cylinder Bore Diameter
|
2.5" (63.5) |
| Clamping Force at 90 PSIG | 441 lbs. (1961n) |
| Input Voltage | 220 VAC |
| Weight | 180.5 lbs. / 81.9 kg |
